Magnet Controls

These reliable controllers include automatic drop and manual drop functionality to energize and de-energize the magnet. There are six models available from 5 amps to 200 amps DC with adjustable release controls.

Model CDS

• Operating range 5 – 20 amps DC (automatic drop model)
• Operating range 1 – 20 amps DC (manual drop model)
• 230 VDC standard, 115 VDC available upon request

Model MC-1A

• Operating range of 20 – 100 amps DC
• Adjustable drop potentiometer
• 230 VDC standard, 24 & 115 VDC available upon request
• Various NEMA ratings available
• Isolated resistor bank compartment prevents damage to front wiring and components

Model MC-1.5A

• Wide operating range of 65 – 130 amps DC
• Adjustable drop rheostat
• 230 VDC standard, 24 & 115 VDC available upon request
• Various NEMA ratings available
• Isolated resistor bank compartment prevents damage to front wiring and components

Model MC-2A

• Operating range of 100 – 150 amps DC
• Adjustable drop rheostat
• Various NEMA ratings available
• Isolated resistor bank compartment prevents damage to front wiring and components

Model RD-3A

• Operating range of 100 – 200 amps DC
• Adjustable drop timer relays
• 230 VDC standard, 115 VDC available upon request
• NEMA 12 enclosure
• Separate resistor bank enclosure
